R9 微型隔离阀
The R9 delivers the liquid flow capabilities of a 16mm valve with a 9mm envelope. A 44% reduction in width with unrivaled flows and pressures up to 100 psi (6.9 bar) in a smaller space. Designed to offer low carryover performance with particulate and crystallization resistant. This valve is ideally suited for today's demanding liquid handling applications. The R9 supports the performance requirements of current and future laboratory and portable instrumentation.
Features
High pressure options available up to 100 psi (6.9 bar)
Easy mounting on 9 mm centers side to side, accommodating dispense over 96 well microplates
Low unswept volume to minimize carryover
Particulate and crystallization resistant
100% tested leak rate ensures a leak tight seal on every valve
CE, REACH, and RoHS compliant
Markets
Clinical Diagnostics
Analytical Chemistry
Agent Detection
Environmental Monitoring
Typical Applications
Sampling
Reagent Addition
Flow Control
Wash
Waste
R9 微型隔离阀，宽度仅为9 mm，适用于结构较为紧凑的设备中。该阀具有低残留性能，保证介质的高效利用。适用于实现液路分配及通断等功能。
